Wireguard Session Manager - Discussion (2nd) thread
- Thread starter Martineau
- Start date
heysoundude
Part of the Furniture
I would think everyone here should be concerned - the protocol seems not only more processor efficient (theoretically faster), but more privacy (and security) -inclined as well, as I understand it:
https://en.wikipedia.org/wiki/IPv6-to-IPv6_Network_Prefix_Translation <- there's an interesting reference link there, and Part 2 has a paragraph that states:
"This means that, should you find yourself having to manage the integration of two separate networks and routing domains following a merger, you’ll be able to route between them without any renumbering (or tricky NAT configuration). But, again, this only works if the ULA subnets have been properly generated using the recommended randomization function." which is exactly what we're doing, managing the integration of our LANs with the greater WAN of the internet itself, right?
And maybe this article (that updates the reference link articles I mentioned) will bring everything together in our heads:
ULA is Broken (in Dual-stack Networks)
ULA is Broken (in Dual-stack Networks). I first started outlining some of the difficulties with Unique Local Addresses (ULA, RFC 4193) in the blog post “IPv6 ULA and NAT. Is It Better Than Global Unicast?” back in January of 2014. First: Why you shouldn’t reflexively deploy ULAs and NAT66Second...
blogs.infoblox.com
Martineau
Part of the Furniture
Brilliant, although perhaps Pastebin would have saved you having to tediously cut up the debug output into separate PMs!
However, I think I can see the problem..
Code:
+ sqlite3 /opt/etc/wireguard.d/WireGuard.db INSERT into session values('wg22','Start','1647599856');
+ sqlite3 /opt/etc/wireguard.d/WireGuard.db SELECT auto FROM servers WHERE peer='wg22';
+ [ Y == S ]wg22 is not defined as a Site-to-site 'server' Peere.g. Your
wg22 'server' Peer is set AUTO=Y rather than AUTO=S
Code:
E:Option ==> peer
Peers (Auto start: Auto=P - Policy, Auto=S - Site-to-Site)
Server Auto Subnet Port Annotate
wg21 Y 10.50.1.1/24,fd36:7ef1:2add:aa88::1/64 11501 # RT-AX88U (IPv4/IPv6) Server 1
wg22 Y 10.50.2.1/24,2a02:c7f:f0c3:1010::1/64 11502 # RT-AX88U (IPv4/IPv6) Server 2Can you issue
Code:
e = Exit Script [?]
E:Option ==> peer wg22 auto=sNow restart wg22 and hopefully the cron job should be created.
Last edited:
ZebMcKayhan
Very Senior Member
I would think everyone here should be concerned - the protocol seems not only more processor efficient (theoretically faster), but more privacy (and security) -inclined as well, as I understand it:
https://en.wikipedia.org/wiki/IPv6-to-IPv6_Network_Prefix_Translation <- there's an interesting reference link there, and Part 2 has a paragraph that states:
"This means that, should you find yourself having to manage the integration of two separate networks and routing domains following a merger, you’ll be able to route between them without any renumbering (or tricky NAT configuration). But, again, this only works if the ULA subnets have been properly generated using the recommended randomization function." which is exactly what we're doing, managing the integration of our LANs with the greater WAN of the internet itself, right?
And maybe this article (that updates the reference link articles I mentioned) will bring everything together in our heads:
ULA is Broken (in Dual-stack Networks)
ULA is Broken (in Dual-stack Networks). I first started outlining some of the difficulties with Unique Local Addresses (ULA, RFC 4193) in the blog post “IPv6 ULA and NAT. Is It Better Than Global Unicast?” back in January of 2014. First: Why you shouldn’t reflexively deploy ULAs and NAT66Second...
Thanks for the interesting link! The main reason for using ULA+NPT6 would be to use Wireguard server with a dynamic wan prefix. Unfortunately the links does not address this.
Altough as it seems NPT6 is available in our routers and hoping for some good results from @archiel as to wheither it is working or not. If it is working we should, by no doubt, use that instead of NAT6 (masquarade).
But the command is abit tricky and when trying to write script to automatically do this I realized they would need something like wgm "Expand_Ipv6" and "Compress_Ipv6" and eventually to the conclution that I should leave it to more experienced scripters. I don't know if it is in the stars that it comes into wgm, but it is were it belongs.
Currently our routers don't seem to route ula to wan at all, packages don't even reach forwarding, so unwillingly we reached the same conclusion as in your links. Right now the only option is to use some global address (could be from reserved space, like aa-space). Altough a non-optimal solution it would basically solve the problems in the link. But for how long until there are conflicts?
Edit: aah, now I get why I sometimes get the "you have ipv6 but your device does not seem to want to use it" message... My lan is on ula... makes perfect sense now!
Last edited:
JGrana
Very Senior Member
LOL, indeed! I didn't realize until the third copy/pasteBrilliant, although perhaps Pastebin would have saved you having to tediously cut up the debug output into separate PMs!
Ahh, I see. I think I changed it quite some time ago to wg22.
In any case, wg_manager doesn't allow the auto=2 for wg22:
Code:
E:Option ==> peer wg22 auto=s
***ERROR Invalid Peer Auto='s' wg22'Can I rename it to wg21? Or maybe just re-create new on both ends. It's wg22 at both Home and Cabin.
Martineau
Part of the Furniture
Can you try setting
wg22 manually?
Code:
e = Exit Script [?]
E:Option ==> diag sqlX
<snip>
SQLite version 3.33.0 2020-08-14 13:23:32
Enter ".help" for usage hints.
Code:
sqlite> UPDATE servers SET auto='S' WHERE peer='wg22';
sqlite> .quitJGrana
Very Senior Member
Ok, did the above, restarted server and now cru l shows the WireGuard_ChkDDNSwg22 entry.
Thanks!
heysoundude
Part of the Furniture
you're most welcome! I like to help...or nudge a train of thought here or there
Fingers crossed @archiel has success/insight/lightning bolt of brilliance. Forward on!
ZebMcKayhan
Very Senior Member
FYI, just changed my lan prefix to: aaff:a37f:fa75:1::1/64 instead of fdff:a37f:fa75:1::1/64 and I went from good/mediocre score to great score on test sites. Even the google ipv6 test seems satisfied. Jackpot!you're most welcome! I like to help...or nudge a train of thought here or there
Fingers crossed @archiel has success/insight/lightning bolt of brilliance. Forward on!
ZebMcKayhan
Very Senior Member
@Martineau
After last update, log file is filling up with:
Altough I use scribe to send these to discard box, is this intentional? My vpn has been almost weirdly stable for months, it's hardly changing ip every 5 min.
After last update, log file is filling up with:
Code:
Mar 18 22:30:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 1834 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla'
Mar 18 22:30:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 1837 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'
Mar 18 22:35:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 5621 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla
Mar 18 22:35:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 5623 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'
Mar 18 22:40:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 8206 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla
Mar 18 22:40:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 8207 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'
Mar 18 22:45:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 12037 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'
Mar 18 22:45:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 12034 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla
Mar 18 22:50:01 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 14945 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'
Mar 18 22:50:01 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 14944 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla
Mar 18 22:55:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 18539 DDNS Endpoint wireguard.net:48574 re-Resolved for 'wg11' Public Key 'blablabla
Mar 18 22:55:00 RT-AC86U-D7D8 (wg_ChkEndpointDDNS.sh): 18540 DDNS Endpoint us.wireguard.net:42911 re-Resolved for 'wg12' Public Key 'blablabla'Altough I use scribe to send these to discard box, is this intentional? My vpn has been almost weirdly stable for months, it's hardly changing ip every 5 min.
Last edited:
Martineau
Part of the Furniture
Jason's recommended script appears to blindly resolve the DDNS when the connection is dormant (which makes sense?) presumably in an attempt to ensure that the next packet exchange will resolve correctly.
I guess there is no need to write the message - so I'll suppress it in the next release.
ZebMcKayhan
Very Senior Member
Updated Ipv6 server part for dynamic wan ips, it is now confirmed working:
https://github.com/ZebMcKayhan/WireguardManager/edit/main/README.md#setup-wg-server
Put in the NPT6 part as well but mostly for reference and still experimental.
https://github.com/ZebMcKayhan/WireguardManager/edit/main/README.md#setup-wg-server
Put in the NPT6 part as well but mostly for reference and still experimental.
ZebMcKayhan
Very Senior Member
Thanks,Uploadedwireguard_managerBeta v4.16b6
Minor bug fix, but should (finally) improve the statistics metrics displayed on screen for 'client' Peers.
P.S. @ZebMcKayhan In fixing the comment/tag update issue, this may also fix the inability to delete your 'server' Peers, together with suppressing (by default) the re-resolv DDNS Syslog message although they can now be optionally issued.
Update wg_manager.sh · MartineauUK/wireguard@8f33e03
FIX: Unable to change comment tag for 'device' Peer Default 'iPhone X 10.50.1.3/32 10.88.8.1 0.0.0.0/0 # iPhone "Device"'...github.com
To upgrade use
Code:e = Exit Script [?] E:Option ==> uf dev
Some error message when creating the server:
Code:
E:Option ==> peer new ip=192.168.100.1/24 ipv6=aaff:a37f:fa75:100:100::1/120
Press y to Create (IPv4/IPv6) 'server' Peer (wg21) 192.168.100.1/24,a
aff:a37f:fa75:100:100::1/120:11501 or press [Enter] to SKIP.
y
Creating WireGuard Private/Public key-pair for (IPv4/IPv6) 'server' P
eer wg21 on RT-AC86U (v386.5_0)
Press y to Start (IPv4/IPv6) 'server' Peer (wg21) or press [Enter] to
SKIP.
y
Requesting WireGuard VPN Peer start (wg21)
WireGuard-serverwg21: Initialising WireGuard VPN (IPv6) [aaff:a37f:fa
75:6::1] 'Server' Peer (wg21) on 192.168.100.1,[aaff:a37f:fa75:100:100::1]:11
501 (# RT-AC86U (IPv4/IPv6) Server 1)
Error: inet6 prefix is expected rather than "192.168.100.1/24,aaff:a37f:fa75:
100:100::1/120".
WireGuard-serverwg21: Initialisation complete.For some reason, the server is created on aaff:a37f:fa75:6::1 which I dont know how it obtain. This is wl1.2 subnet and does not exist in nvram variables or as default route or on eth0.
The error message suggest some parsing/scrubbing issue.
Edit: still cant delete device peer
peer test del properly. Device test is removed from the list when issuing peer and the conf files are removed, still peer wg21 del asks to re-assign the device test.Edit2:
Code:
E:Option ==> start wg21 debug
Requesting WireGuard VPN Peer start (wg21)
WireGuard-serverwg21: Initialising WireGuard VPN (IPv6) [aaff:a37f:fa
75:6::1] 'Server' Peer (wg21) on 192.168.100.1,[aaff:a37f:fa75:100:100::1]:11
501 (# RT-AC86U (IPv4/IPv6) Server 1)
[#] ip link add dev wg21 type wireguard
[#] ip -6 link add dev wg21 type wireguard
[#] wg set wg21 fwmark 11501
[#] wg setconf wg21 /tmp/wg21.11765 #(/opt/etc/wireguard.d/wg21.conf)
[#] ip link set up dev wg21
[#] ip -6 link set up dev wg21
[#] ip -6 address add dev wg21 192.168.100.1/24,aaff:a37f:fa75:100:100::1/120
Error: inet6 prefix is expected rather than "192.168.100.1/24,aaff:a37f:fa75:
100:100::1/120".
[#] ifconfig wg21 mtu 1420
[#] ifconfig wg21 txqueuelen 1000
[#] ip route add default dev wg21 table 210
Code:
admin@RT-AC86U-D7D8:/tmp/home/root# ifconfig wg21
wg21 Link encap:UNSPEC HWaddr 00-00-00-00-00-00-00-00-00-00-00-00-00-00
-00-00
UP POINTOPOINT RUNNING NOARP MTU:1420 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
Last edited:
Martineau
Part of the Furniture
I've deleted the commit
Please backout the commit
Code:
e = Exit Script [?]
E:Option ==> uf devPlease can you test the following for the parsing issue....
e.g. issue on the command line
Code:
SUBNET="192.168.100.1/24,aaff:a37f:fa75:100:100::1/120"
Code:
echo $SUBNET
Code:
echo ${SUBNET//,/ }ZebMcKayhan
Very Senior Member
Code:
admin@RT-AC86U-D7D8:/tmp/home/root# SUBNET="192.168.100.1/24,aaff:a37f:fa75:100:100::1/120"
admin@RT-AC86U-D7D8:/tmp/home/root# echo $SUBNET
192.168.100.1/24,aaff:a37f:fa75:100:100::1/120
admin@RT-AC86U-D7D8:/tmp/home/root# echo ${SUBNET//,/ }
192.168.100.1/24 aaff:a37f:fa75:100:100::1/120heysoundude
Part of the Furniture
I feel as if "critical mass" might be achieved shortly, if I'm reading things right.
I wonder if WireGuard's originator might be interested enough to poke his head in at this point...
ZebMcKayhan
Very Senior Member
Cant wait on your feedback after trying it out!
Martineau
Part of the Furniture
Thanks,
I've experienced weird issues like this before...it should always work in a script but in some cases doesn't, so I've reverted to old-skool slower code
Code:
echo ${SUBNET//,/ }
Code:
echo $(echo "$SUBNET" | tr ',' ' ')Anyway uploaded
wireguard_manager Beta v4.16b7Use
Code:
e = Exit Script [?]
E:Option ==> uf devheysoundude
Part of the Furniture
This is a big deal, being able to follow ISP-initiated WAN IP changes - it (if I understand things correctly) does away with needing to set up DDNS tunneling, and maybe even FQDNs with HTTPS certs. Possibly (and this is a stretch) get out from behind IPv4 CGNAT
This would make your router (or should we just call it our WG server?) much more private I think, and tunnel more secure. (basically you're your own VPN)
I'm just not sure how you've accomplished making this change, where in the router GUI to find it; by selecting/configuring Native IPv6, I don't get the option: it auto-populates...I may be missing something. Is it a command line thing, why you've added scripts? (the thought occurred when reading the github that anyone with a /48 should know how to amend the scripts themselves if they've come this far) (it's not the best time of day for me to use my brain on this stuff)
(NOTE: to anyone trying to follow this pages-long thread, STOP. Go to the README on Zeb's github. it's all very clear there, laid out in easy progression)
ZebMcKayhan
Very Senior Member
Thanks, no problems with creating server peer, or delete devices anymore:
Code:
E:Option ==> peer new ip=192.168.100.1/24 ipv6=aaff:a37f:fa75:100:100::1/120
Press y to Create (IPv4/IPv6) 'server' Peer (wg21) 192.168.100.1/24,a
aff:a37f:fa75:100:100::1/120:11501 or press [Enter] to SKIP.
y
Creating WireGuard Private/Public key-pair for (IPv4/IPv6) 'server' P
eer wg21 on RT-AC86U (v386.5_0)
Press y to Start (IPv4/IPv6) 'server' Peer (wg21) or press [Enter] to
SKIP.
y
Requesting WireGuard VPN Peer start (wg21)
WireGuard-serverwg21: Initialising WireGuard VPN (IPv6) [aaff:a37f:fa
75:6::1] 'Server' Peer (wg21) on 192.168.100.1,[aaff:a37f:fa75:100:100::1]:11
501 (# RT-AC86U (IPv4/IPv6) Server 1)
WireGuard-serverwg21: Initialisation complete.
<snip>
E:Option ==> peer test del
Deleting 'device' Peer (test)
Press y to CONFIRM or press [Enter] to SKIP.
y
'device' Peer test removed from 'server' Peer (wg21)
'device' Peer test DELETED
WireGuard 'server' Peer needs to be restarted to remove 'client' Peer
Press y to restart 'server' Peer (wg21) or press [Enter] to SKIP.
y
Requesting WireGuard VPN Peer restart (wg21)
Restarting Wireguard 'server' Peer (wg21)
<snip>
E:Option ==> peer wg21 del
Deleting 'server' Peer (wg21)
Press y to CONFIRM or press [Enter] to SKIP.
y
Requesting WireGuard VPN Peer stop (wg21)
WireGuard-serverwg21: WireGuard VPN (IPv6) [aaff:a37f:fa75:6::1] 'Ser
ver' Peer (wg21) on 192.168.100.1,[aaff:a37f:fa75:100:100::1]:11501 (# RT-AC8
6U (IPv4/IPv6) Server 1) Terminated
'server' Peer wg21 DELETEDtried out the new experimental ula generator, and it worked after installing the required package:
Code:
E:Option ==> peer new ipv6 ula
Press y to Create (IPv4/IPv6) 'server' Peer (wg21) 10.50.1.1/24,fd00:
50:1::1/64:11501 or press [Enter] to SKIP.
E:Option ==> ipv6 ula
*** ERROR IPv6 ULA generate function requires Entware 'date' module (
coreutils-date)
admin@RT-AC86U-D7D8:/tmp/home/root# opkg install coreutils-date
Installing coreutils-date (8.32-6) to root...
Downloading https://bin.entware.net/aarch64-k3.10/coreutils-date_8.32-6_aarch
64-3.10.ipk
Configuring coreutils-date.
E:Option ==> ipv6 ula
On Tue 22 Mar 2022 07:50:54 PM CET, Your IPv6 ULA is 'aaf6:2013:d6bd:
:1/64' (Use 'aaf6:2013:d6bd::1/64' for Dual-stack IPv4+IPv6)
E:Option ==> peer new ipv6 ula
Press y to Create (IPv4/IPv6) 'server' Peer (wg21) 10.50.1.1/24,fd06:
cb22:5380::1/64:11501 or press [Enter] to SKIP.wierd that ipv6 ula gives aa prefix in both cases, thought it would give fd and suggest to use aa. But when creating the peer it gives fd (which makes sense if the generated ula proposed fd).
Great work!
Similar threads
Similar threads
Similar threads
-
New Addon - ChatAI - have a chat session with Googles Gemini AI Bot- Started by JGrana
- Replies: 2
-
Solved How do I remove WG Manager from amtm without resetting amtm?
- Started by DJones
- Replies: 2
-
VPNMON VPNMON-R3 - Early, early alpha discussion, progress & screenshots- Started by Viktor Jaep
- Replies: 17
Latest threads
-
-
Voxel Custom firmware build for R9000/R8900 v. 1.0.4.77HF- Started by Voxel
- Replies: 0
-
-
WARNING - router is in manufacturing mode, and can behave unexpectedly (did you mess with your bootloader?)
- Started by jamesp10
- Replies: 1
-
Voxel Custom firmware build for R7800 v. 1.0.2.111SF
- Started by Voxel
- Replies: 2
Support SNBForums w/ Amazon
If you'd like to support SNBForums, just use this link and buy anything on Amazon. Thanks!
Sign Up For SNBForums Daily Digest
Get an update of what's new every day delivered to your mailbox. Sign up here!
